| SPECIFICATIONS |
|
| Nominal Diameter |
6X9” / 162*235mm |
| Nominal Impedance |
4 ohm |
| RMS Power Handing |
120W |
| MAX Power Handing |
360W |
| Sensitivity (1w/1m) |
92dB |
| Frequency Response |
31.5Hz-20KHz |
| Recommended HI Pass Crossover |
50Hz |
| Number of ways |
2-Way |
| MIDRANGE |
|
| Voice Coil Diameter |
1.2” / 30.4mm |
| Voice Coil Former Material |
KSV |
| Winding Material |
EISV |
| Cone Material |
Glass fiber |
| Surround Material |
Rubber |
| Basket Material |
Steel |
| Magnet Material |
Barium Ferrite |
| Magnet Weight |
550g |
| TWEETER |
|
| Nominal Diameter |
1" (25.4mm) |
| Voice Coil Diameter |
0.8"(ø20.4mm) |
| Voice Coil Former Material |
KSV |
| Winding Material |
EISVM |
| Diaphragm Material |
PEI |
| Magnet Material |
Neodymium |
| Magnet Weight |
8.5g |
| MEASUREMENT |
|
| Overall Diameter |
6.37x9.25” /162*235mm |
| Overall Depth |
3.66” / 93mm |
| Front Mount Baffle Cutout |
5.94x8.70” / 151*221mm |
| Mouting Depth |
3.22” / 82mm |
| Motor Diameter |
4.09” / 104mm |
