| Throat Diameter |
2"/50.8mm |
| Installation Type |
Bolt-on |
| Nominal Impedance |
8 Ohms |
| Program Power Handling |
320W |
| Peak Power Handling |
640W |
| AES Power Handling |
160W |
| Sensitivity |
111dB |
| Frequency Response |
630Hz-20KHz |
| Recommended HI Pass Crossover |
900 Hz |
| Motor |
PRO-D1 |
| Voice Coil Diameter |
2.03"/51mm |
| Voice Coil Former Material |
Kapton |
| Winding Material |
CCA |
| Diaphragm Material |
Titanium |
| Magnet Material |
Ferrite |
| Magnet Weight |
35oz |
| Measurements |
|
| Overall Diameter |
7"/180mm |
| Overall Depth |
5.3"/134.7mm |
| Bolt Pattern/Type |
5.5mm hole-6.3"/161 mm Diameter |
| Mounting Depth |
4.9"/125.8mm |
| Mounting Hole Diameter |
5.7"/145mmm |
