| Specifications |
| POWER |
|
| Total Watts (Peak) |
1440 Watts |
| RMS Power @ 4 ohm |
4 x 120 Watts |
| RMS Power @ 2 ohm |
4 x 200 Watts |
| RMS Power @ 4 ohm Bridge |
2 x 350 Watts |
| AUDIO |
|
| Frequency Response |
20Hz - 20KHz |
| Signal to Noise Ratio 1W@4Ω |
>90 dB |
| Efficiency @ 4 ohm |
94% |
| Input Impedance |
>20KΩ |
| Channel Separation |
>-70 dB |
| Total Harmonic Distortion (THD) |
<0.1 % |
| Low Level Input Range |
270mV - 5.6V |
| Selectable X-Over |
HPF/FULL/LPF |
| X-Over Filter Range |
50Hz-4KHz |
| FEATURES |
|
| Amplifier Class |
Digital (D) |
| Amplifier Type |
Full Range Digital Marine Amplifier |
| Number of Channels |
4 |
| Minimum Impedance |
2 OHM / Ch (4 OHM Bridge) |
| LED Indicator |
Protection (Red) | Power (Blue) |
| Power Input Size |
8 Ga |
| Fuse |
2 x 40A |
| Thermal Protection |
Yes |
| Over-Load Protection |
Yes |
| Short Circuit Output Protection |
Yes |
| Voltage Input Protection |
Yes (9.5-16V) |
| Body Color | Finish |
Black Anodize |
| 2CH | 4CH Input Selector |
Yes |
| Waterproof Rating |
IPX7 |
| UV / Salt Fog Protection |
Yes |
| Direct Power Harness Design |
Yes |
| Surface Mount Component Technology |
Yes |
| Marine Grade Fuse Holder |
Yes |
| MEASUREMENT |
|
| Overall Length |
10" / 253mm |
| Overall Wide |
4.5" / 116mm |
| Overall Height |
1.9" / 48.5mm |
| Heatsink Length |
8.5" / 216mm |
| Gross Single Unit Weight |
1.8Kg |
